8 Bits WS2812 5050 RGB LED Full Color LED Lamp-white
$0.281pcs
The WS2812 5050 SMD RGB LED is an individually addressable smart LED with built-in control circuitry, enabling vibrant color effects and precise digital control using a single data line.
| Dimensions | 57.1 × 10.6 × 3 mm |
|---|---|
| Brand |
easyelecmodule |
5133 in stock
Add Your Heading Text Here
WS2812 Square Board - White Version
Product Description
This product is a WS2812B RGB (5050 package) full-color smart LED. It utilizes a single-wire communication protocol, which simplifies wiring and significantly reduces the communication load on the microcontroller (MCU).
Each LED is equipped with built-in protection and an internal signal reshaping circuit. Every LED acts as an individual pixel; upon receiving a signal, it reshapes the waveform before outputting it to the next pixel. This ensures that signal distortion does not accumulate over long chain lengths.
Each of the three primary colors (red, green, and blue) in every pixel can achieve 256 levels of brightness, enabling the display of 16,777,216 (256³) true full colors. The refresh rate is no less than 400Hz.
Furthermore, each LED board or strip is fitted with an output port, allowing for easy cascading with additional boards to create larger displays.
Key Features
- The IC control circuit and the LED share a single power supply.
- The control circuit and RGB chip are integrated into a single 5050 package component, forming a complete, externally-controlled pixel.
- Built-in signal reshaping circuit ensures waveform distortion does not accumulate by reshaping the signal at each pixel before output.
- Built-in power-on reset (POR) and brown-out reset (BOR) circuits.
- Each of the three primary colors (RGB) can display 256 brightness levels, achieving 16,777,216 (24-bit) true colors.
- PWM (Port Scanning) Frequency: 2 KHz.
- Serial cascade interface for data reception and decoding via a single signal line.
- No additional circuitry required for transmission distances of up to 5 meters between any two points.
- Supports at least 1024 cascaded pixels at a refresh rate of 30 fps.
- Data transmission speed up to 800 Kbps.
- High color consistency and cost-effective.
PIN
| Serial Number | Symbol | Pin Name | Function Description |
|---|---|---|---|
| 1 | VCC | Power Supply | Power supply pin |
| 2 | DOUT | Data Output | Control data signal output |
| 3 | GND | Ground | Signal ground and power ground |
| 4 | DIN | Data Input | Control data signal input |
LED Specifications
| LED | Reference Value |
|---|---|
| Static Current | 0.7mA |
| RGB Channel Constant Current | 16mA |
| Red Light Luminance (Central Value) | 600mcd |
| Green Light Luminance (Central Value) | 1200mcd |
| Blue Light Luminance (Central Value) | 300mcd |
| White Light Luminance (Central Value) | 2100mcd |
| Red Light Wavelength | 620-630nm |
| Green Light Wavelength | 520-530nm |
| Blue Light Wavelength | 465-475nm |
Product Effects Demo Product Effects Demo
