PT2399 Microphone Reverb Board
$2.501pcs
The PT2399 Reverb Board creates analog reverb effects using delay technology. It offers great value for money, making it ideal for DIY projects and entry-level effect pedals. It is commonly used in audio DIY setups and home applications.
| Dimensions | 50 × 50 mm |
|---|---|
| Brand |
easyelecmodule |
3156 in stock
Product Introduction
The PT2399 Reverb Board is a reverb module that uses the PT2399 chip to generate analog reverb via delay. For proper operation, the recommended connection order is: Microphone → Microphone Preamplifier → Microphone Reverb Board (this module) → Power Amplifier. Therefore, to use this module, you usually need to pair it with additional components like a microphone preamplifier; otherwise, the effect will not work properly.
Electrical Parameters of the Reverb Board
Operating voltage: DC 6-15V
DimensionDiagram
Notes
R27 is the resistor for adjusting reverb depth. If you need to modify the depth:
1.Remove R27.
2.Solder a potentiometer (20kΩ or 50kΩ recommended) to the S–G–G pads for adjustment.
Wiring Instructions
Usage Instructions
- Adjust the reverb effect using the potentiometer.
- Follow this connection order: Microphone → Microphone Preamplifier → Microphone Reverb Board (this module) → Power Amplifier.
Demo Video
PT2399 Electrical Parameters
Power Supply & Power Consumption Parameters
| Parameter | Value |
|---|---|
| Operating Voltage (VDD) | 4.5V – 5.5V (Typical 5V) |
| Maximum Allowable Voltage | 6.5V (Absolute Maximum) |
| Operating Current | ≈ 30 mA (Typical) |
| Standby Current | ≈ 15–20 mA |
| Power Consumption | ≈ 150 mW |
Audio interface parameters
Input:
| Parameter | Value |
|---|---|
| Input Type | Analog audio |
| Input Impedance | ≈ 50 kΩ |
| Input Level (Typical) | 100 mVrms |
| Maximum Input Level | ≈ 300 mVrms (distortion may occur if exceeded) |
| Input Bias | Internal 2.5 V bias |
Output:
| Parameter | Value |
|---|---|
| Output Type | Analog audio |
| Output Impedance | ≈ 2 kΩ |
| Maximum Output Level | ≈ 1 Vpp |
| Output Bias | Internal 2.5 V bias |
Audio performance parameters
| Parameter | Value |
|---|---|
| Signal-to-Noise Ratio (SNR) | ≈ 90 dB (short delay) |
| Total Harmonic Distortion + Noise (THD+N) | ≈ 0.5% (short delay) |
| Frequency Response Range | 20 Hz – 10 kHz (varies with delay) |
| Delay Jitter | Becomes more noticeable as delay increases |
