SP3232 TTL to RS232 module gold – plated small board
$0.491 pcs
RS232 SP3232 TTL to RS232 module, RS232 to TTL flashing cable serial port module, gold-plated board.
| Dimensions | 20 × 16 mm |
|---|---|
| Brand |
easyelecmodule |
541 in stock
Introduction
The serial port of the single-chip microcomputer must undergo level conversion before it can communicate with the standard RS-232. The conversion chips for 5V are generally MAX232 or SP232, and for 3.3V, they are generally MAX3232 or SP3232.
The RS232 interface is a general serial communication standard, used to establish a reliable communication channel between a computer and external devices to achieve bidirectional data transmission. Through the RS232 interface, a computer can connect with various peripheral devices such as printers, modems, sensors, etc., to realize the control of devices and data exchange.
Applicable products: printers, scanners, sensors, etc.
It is commonly used in industrial automation control systems and communication equipment fields.
Connection Instructions:
TTL (UART) Port:
- VCC: Connect to 3V–5.5V DC power
- GND: Connect to GND
- TXD: Connect to the RXD pin of the external device’s TTL port
- RXD: Connect to the TXD pin of the external device’s TTL port
RS232 Port:
- RXD: Connect to the TXD pin of the external device’s RS232 port
- TXD: Connect to the RXD pin of the external device’s RS232 port
- GND: Connect to GND
Main Applications:
- Enable communication between MCUs (such as microcontrollers, ARM) and computers via the computer’s serial (COM) port.
- Modify radio equipment, flash mobile phones/XBOX360, work with GPS devices, perform car diagnostics, flash DVDs, repair hard drives, and upgrade set-top boxes.
- Serial port expansion for devices.
