LTC1871 Boost Power Supply Module High Power 100W
$9.111pcs
LTC1871 high‑power boost module, 100W robust output for heavy loads! High efficiency, low ripple, rock‑solid stability. Compact and easy to integrate, perfect for DIY, industrial and lighting.
| Dimensions | 67.0 × 43.0 mm |
|---|---|
| Brand |
easyelecmodule |
3512 in stock
LTC1871 Parameter
| Model | LTC1871 Boost Power Supply Module |
|---|---|
| Input voltage | 3~35V DC (Note: If the input voltage is less than 4V, the onboard voltmeter will fail) |
| Output voltage | 3.5~35V DC (This board is a boost board, output voltage ≥ input voltage) |
| Output power | 75W (When both input and output voltages are higher than 20V, the power can reach 128W) |
| Output ripple | 24mV (typ) |
| Short circuit protection | have (Current limited to 14A) |
| Size | 67*43*12 mm (without copper standoffs) |
| Input current | 9A (MAX) |
| Output current | 6A (MAX) |
| Conversion efficiency | 96.7% (maximum) |
| Onboard voltmeter range | 4~40V, error ±0.1V |
| Input reverse connection protection | No (If needed, please connect a high-current diode in series with the input) |
Note: When connecting a high-power load, the inrush current is very large at startup, which may trigger current limiting and self-locking protection. It is recommended to start the device first and then connect the load.
LTC1871 Hardware Diagram
LTC1871 New Advantage
1. Onboard LED working indicator, making the working status more intuitive.
2. One-key switch for the on/off of the nixie tube, and one-key switch for the measurement of input and output voltage. (When the onboard voltage indicator “IN” is on, it displays the input voltage. When “OUT” is on, it displays the output voltage.)
3. This product strongly introduces the program self-calibration function for voltage display value! There will never be a problem of inaccurate voltmeter.
LTC1871 Application
1. DIY a regulated power supply, with an input of 5V, and an adjustable output of 5-35V.
2. Power your electronic devices, and the output value can be set according to your system voltage. For example, 7.4V or 12V can be boosted to 19V to power a laptop.
3. It can power your various digital products.
