Name: MQ-6 Application scenario – Easyelecmodule
Price: 2.99 USD
Availability: InStock

MQ-6 Application scenario

$2.991pcs

The DIY MQ6 is an LPG gas sensor for propane and butane detection, offering a 200–10,000 ppm range with adjustable analog and digital outputs for simple, reliable gas monitoring.

Dimensions

32 × 20 × 22 mm

Brand

easyelecmodule

5525 in stock

DESCRIPTIONS AND FEATURES

MQ-6 Liquefied Gas Sensor

Description

Designed specifically for liquefied petroleum gas (LPG) detection, the DIY MQ6 Gas Sensor Module excels at sensing the concentration of LPG—primarily composed of propane and butane—in the surrounding air. It boasts a detection range spanning 200 to 10,000 ppm, covering the critical concentration levels needed for effective monitoring.

The module features dual output capabilities for flexible usage: an analog output that varies in direct correlation with ambient gas concentration, and a convenient digital output for straightforward triggering. An onboard potentiometer allows users to customize the threshold—setting the maximum gas concentration limit that, when exceeded, activates the digital output.

Operation is remarkably simple: supply the module with a 5V DC power source, adjust the desired threshold via the potentiometer, and it immediately begins detecting LPG concentration in its vicinity. An integrated LED indicator provides clear visual feedback, illuminating whenever target gases are detected.

For seamless integration with electronic systems, the digital output can be easily connected to microcontrollers and other circuits. Meanwhile, the analog output can be linked to a microcontroller’s ADC (Analog-to-Digital Converter), enabling access to a wide spectrum of precise sensor readings for detailed analysis.

Features & Specifications

FEATURE	DESCRIPTION
5V operation	Operates on 5V DC power
LEDs for output and power	Indicates output and power status
Output sensitivity adjustable	Sensitivity can be adjusted for precise detection
Analog output 0V to 5V	Provides analog signal output from 0V to 5V
Digital output 0V or 5V	Provides digital output with either 0V or 5V
Low Cost	Economical design for cost efficiency
Fast Response	Quick sensor reaction time for real-time applications
Stable and Long Life	Reliable performance with extended operational lifespan
Both Digital and Analog Outputs	Supports both digital and analog signal output modes

mq6 gas sensor datasheet
